WebSharper Extensions for GlMatrix Public

glMatrix is designed to perform vector and matrix operations blazing fast, and will help you get the most out of your browser's Javascript engine for numerical computations and 2D/3D graphics.

Library home Browse source code Example

Nuget

Install-Package WebSharper.GlMatrix

Overview

This WebSharper Extension provides a set of classes and functions almost identical to the ones documented in glMatrix, version 2.2.0. When used in WebSharper projects, these stub classes delegate the work to the actual classes implemented by the browser.

After adding the reference to the project all the classes can be found under the IntelliFactory.WebSharper.GlMatrix module.

Usage

The GlMatrix WebSharper extension is as far as possible a one-to-one mapping of glMatrix. Therefore, this documentation will only discuss the differences between glMatrix and the WebSharper extension. For a complete reference, see the glMatrix homepage.

Differences with the JavaScript API

In order to enforce strong typing and take advantage of F# features such as method overloading, we made a few modifications over the glMatrix API.

  • While glMatrix works on Float32Array objects, the WebSharper extension defines classes for each one of Mat2, Mat3, Mat4, Vec2, Vec2d, Vec3, Vec4 and Quad. These classes inherit from the standard Float32Array, which allows you to pass them directly to WebGL methods such as the Uniform series.

Using matrix transformations with WebGL

As the name suggests, glMatrix is mainly intended as a toolbox for coordinate transformation for WebGL. The following example shows a typical use to set the projection and modelview matrices of a given WebGL shader program.

1
2
3
4
5
6
7
8
9
10
11
let SetupView (gl : WebGLRenderingContext, program : WebGLProgram) =
    // Set the projection matrix
    let proj = Mat4.Perspective(Mat4.Create(), 45., 4./3., 0.1, 1000.)
    let u_projection = gl.GetUniformLocation(program, "projectionMatrix")
    gl.UniformMatrix4fv(u_projection, false, proj)

    // Set the modelview matrix
    let cameraPosition = Mat4.Identity(Mat4.Create())
    Mat4.Translate(cameraPosition, cameraPosition, Vec3.FromValues(0.2, 2.3, -5.2)) |> ignore
    let u_modelview = gl.GetUniformLocation(program, "modelviewMatrix")
    gl.UniformMatrix4fv(u_modelview, false, cameraPosition)
